2011-2020 F150 / RAPTOR 3.5L ECOBOOST BILLET TURBO ADAPTER KIT

THE FULL RACE F150 3.5L ECOBOOST BILLET TURBO ADAPTER KIT ALLOWS YOUR FACTORY OR UPGRADED TURBO TO FLOW WITH LESS RESTRICTION. WORKS GREAT WITH OEM TURBOS. DESIGNED TO PAIR BEST WITH GARRETT POWERMAX OEM+ UPGRADE TURBOS, FOUND HERE

WHEN GARRETT BEGAN DEVELOPMENT ON THE POWERMAX STAGE 2 UPGRADE TURBOS, IT BECAME CLEAR THE STOCK ADAPTORS ARE WAYY TOO SMALL – AND EVEN AFTERMARKET ADAPTERS LIKE SPD STILL WOULD BOTTLENECK THE TURBINE WHEEL.  FULL-RACE DEVELOPED THESE TO BE THE LARGEST DIAMETER AND HIGHEST FLOWING TURBO ADAPTER FOR THE ECOBOOST ENGINES.  THEY HAVE OVER 20% MORE FLOW THAN COMPETITOR PRODUCTS.

TECHNICAL INFO:

• LARGEST TURBINE OUTLETS ON THE MARKET (64.5MM)
• 50.4% MIN. AREA INCREASE OVER OEM
• PORT MATCHED TO GARRETT POWERMAX STAGE 2 TURBINE HOUSING
• SMOOTHER FLOW & REDUCED PRESSURE DROP IMPROVES POWER AND SPOOL TIME
• CNC MACHINED FROM BILLET 304 STAINLESS STEEL
• INCLUDES NEW OEM HARDWARE

TURBO DOWNPIPE ADAPTER KIT INCLUDES:

• 2 X BILLET TURBO ADAPTERS
• 1 X TUBE OF HIGH TEMP RTV*
• 4 X FORD OEM STUDS
• 4 X FORD OEM NUTS

*DUE TO THE LARGER ADAPTER SIZE, OEM GASKETS ARE NOT REQUIRED OR RECOMMENDED.  THESE BILLET ADAPTERS ARE MACHINED PERFECTLY FLAT, SO HIGH TEMP RTV LIGHTLY APPLIED IS ALL YOU’LL NEED
